CNY70 IR reflective sensor

The CNY70 is a reflective sensor that includes an infrared emitter and phototransistor in a leaded package with a daylight blocking filter.

These work great as close-range proximity sensors, tachometers, or line following sensors.

SPECIFICATIONS:

Emitter
Emitter Wavelength 950nm
Forward Current (Max) 50mA
Forward Voltage 1.25-1.6V
Power Dissipation 100mW
Detector
Detector Type Phototransistor
Filter Daylight Blocking
Collector Current (Max) 50mA
Power Dissipation 100mW
Dimensions (Excluding Pins)
Length 7mm (0.3")
Width 7mm (0.3")
Height 6mm (0.24")
WEIGHT 0.4g (0.02oz)

4N26 OPTOCOUPLER IC

The 4N26 family is an industry standard single channel phototransistor coupler.DIP6

Each optocoupler consists of galliumarsenide infrared LED and a silicon NPN

OPTOCOUPLER, PHOTOTRANSISTOR, 5000VRMS No. of Channels:1 Channel Optocoupler Case Style:DIP No. of Pins:6Pins Forward Current If Max:60mA Isolation Voltage:5kV CTR Min:20% Packaging:Each Product Range:- Input Current:50mA No. of Channels:1 Operating Temperature Max:100?C Operating Temperature Min:-55?C Operating Temperature Range:-55?C to +100?C Optocoupler Output Type:Phototransistor Output Voltage:70V Output Voltage Max:30V

4N27 OPTOCOUPLER IC
The 4N27 family is an industry standard single channel phototransistor coupler.DIP6

Each optocoupler consists of galliumarsenide infrared LED and a silicon NPN

OPTOCOUPLER, PHOTOTRANSISTOR, 5000VRMS No. of Channels:1 Channel Optocoupler Case Style:DIP No. of Pins:6Pins Forward Current If Max:60mA Isolation Voltage:5kV CTR Min:20% Packaging:Each Product Range:- Input Current:50mA No. of Channels:1 Operating Temperature Max:100?C Operating Temperature Min:-55?C Operating Temperature Range:-55?C to +100?C Optocoupler Output Type:Phototransistor Output Voltage:70V Output Voltage Max:30V

4N28 OPTOCOUPLER IC
The 4N28 family is an industry standard single channel phototransistor coupler.DIP6

Each optocoupler consists of galliumarsenide infrared LED and a silicon NPN

OPTOCOUPLER, PHOTOTRANSISTOR, 5000VRMS No. of Channels:1 Channel Optocoupler Case Style:DIP No. of Pins:6Pins Forward Current If Max:60mA Isolation Voltage:5kV CTR Min:20% Packaging:Each Product Range:- Input Current:50mA No. of Channels:1 Operating Temperature Max:100?C Operating Temperature Min:-55?C Operating Temperature Range:-55?C to +100?C Optocoupler Output Type:Phototransistor Output Voltage:70V Output Voltage Max:30V

CNY71 Optocoupler Optoisolator DIP 6 with bedirection led input

Product Category: Transistor Output Optocouplers
RoHS:
Package/Case: DIP-6
Output Type: NPN Phototransistor
Number of Channels: 1 Channel
If - Forward Current: 10 mA
Maximum Collector Emitter Voltage: 70 V
Maximum Collector Current: 100 mA
Isolation Voltage: 5000 Vrms
Maximum Collector Emitter Saturation Voltage: 0.4 V
Vf - Forward Voltage: 1.65 V
Vr - Reverse Voltage: 6 V
Pd - Power Dissipation: 150 mW
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 100 C

CNX62A OPTOCOUPLER IC

CBX62A Opto Coupler. In: 6V 60mA, Out: 50V 40mA. CTR: 40% min. No Base 6DIL

OPTO INTEGRATED CIRCUIT CNX83A DIP-6
Type Forward voltage: 1.2 V
Type Forward current: 10 mA
Max. Forward voltage: 1.5 V
Max. Forward current: 100 mA
Collector-emitter voltage: 50 V
Collector current: 100 mA
Isolation voltage I/O: 5300 V
CTR: 10 - 320%
6-pin dual inline

MOC3021 OPTO ISOLATOR TRIAC 6DIP

MOC3021 - OPTO ISOLATOR WITH TRIAC OUTPUT 6DIP

The MOC3021 is an optically Isolated Triac Driver Device, contains a GaAs infrared emitting diode and a light activated silicon bilateral switch, which functions like a triac. This device is designed for interfacing between electronic controls and power triacs to control resistive and inductive loads for 115VAC operations.
Features:-

• Excellent IFT stability—IR emitting diode has low degradation

• High isolation voltage—minimum 5300 VAC RMS

• Underwriters Laboratory (UL) recognized—File #E90700

• Peak blocking voltage: 400V-MOC3021

• VDE recognized (File #94766)

Applications:- Industrial, Motor Drive & Control, Consumer Electronics

SFH506-36 IR-Receiver/Demodulator Device

SFH506-30 IR-RECEIVER/DEMODULATOR DEVICE

PC817-SMD PC817 OPTO SMD

PC817 SOP-4 SMD Optocoupler

Input
- Forward current IF 60mA
- Peak forward current (1us, pulse) IFP 1A
- Power dissipation 100mW
Output
- Collector current 50mA
- Collector-Emitter voltage 35v
- Emitter-Collector voltage 6v
- Power dissipation 150mW


1. Current conversion ratio CTR (at I F = 5mA, V CE = 5V under CTR: MIN 50%)
2. Insulation voltage between input and output is high (V ISO = 5,000Vrms)
3. Response time (rise time tr: typical value 4µs at V CE = 2V, I C = 2mA, R L = 100 O)

EL814 SMD DOUBLE LED I/P OPTOCOUPLER

The EL814 series of devices each consist of two infrared emitting diodes, connected in inverse parallel, optically coupled to a phototransistor detector.
80V/ISOLATING 5KV
opto-isolator transistor Photovoltaic Output SOP4

MOC3011M OPTOISOLATOR TRIAC 6DIP

MOC3011M OPTOISOLATOR 4.17KV TRIAC 6DIP
Manufacturer:ON Semiconductor

Manufacturer Product Number
MOC3011M

Detailed Description:Optoisolator Triac Output 4170Vrms Channel 6-DIP

MOC3021/SMD OPTO TRIACK 6PINS SMD

MOC3021XSM OPTO TRIACK 6PINS SMD MOC3021XSM 400V MAX/ZERO CROSING VOLTAGE

HCPL2601 OPTO SCHMITT TRIGER 10Mpbs
Broadcom, HCPL-2601-000E DC Input Transistor Output Optocoupler, Through Hole, 8-P

10 MBd digital optocouplers are suited for isolated communication logic interface and control in industrial power systems, factory automation, power supplies, and medical equipment applications.

MOC3052 OPTO TRIACK without zero voltage crossing driver

HCPL2530M OPTOCOUPLER 2 CHANNEL TRANSISTOR

HCPL0600-000E OPTOCOUPLER 1CH/DARLINGTON /3.7KV/10Mbps SO8

Manufacturer: BROADCOM (AVAGO)

Type of optocoupler:optocoupler

Mounting:SMD

Number of channels:1

Kind of output:Darlington

Insulation voltage:3.75kV

Transfer rate:10Mbps

Case:SO8

Turn-on time:24ns

Turn-off time:3µs

Slew rate:10kV/μs
